The diagram above shows a waveform in which energy is transferred from A to B in a time of 2.5 x 10-3s. Calculate the frequency of the wave
Attached Figure / Diagram
A
2.0 x 103Hz
B
1.0 x 103Hz
C
4.0 x 10-2Hz
D
1.0 x 10-3Hz
E
5.0 x 104Hz.
Verified Correct Answer: B.
Physical Principles & Numerical Solution
The waveform moved from A to B in \(2.5 \times 10^{-3}\) seconds.
From the diagram, A to B has \(2\frac{1}{2}\) complete oscillations between it, Therefore, the period of the oscillation is
\(\frac{2.5 \times 10^{-3}}{2.5} = 1 \times 10^{-3} s\)
\(Frequency = \frac{1}{Period}\)
= \(\frac{1}{1 \times 10^{-3}} = 1 \times 10^{3} Hz\)
